Savox’s SB-2263MG Black Edition “High Speed” Low Profile Brushless Metal Gear Servo features a sleek black aluminum center case with laser etched details, as well as a shorter heavy duty wire. These servos combine leading edge technology with super high 12 bit (4096) resolution. These servos also feature a brushless motor/controller unit, and use a ‘bullet proof’ all metal gear set for unmatched strength that makes them ideal for 1/10 touring car and off road applications that require a high speed servo.
Savox Black Edition Features:
- Higher performance due to brushless motor and improved technology
- Fast response
- Incredible torque
- Increased transit speed
- Increased efficiency
- Water resistant with 4 silicon seals implanted
- Strong and precise-made metal gears
- Suitable for 1/10 touring car and off road
*NOTE:Certain combinations of receiver and ESC have been found to cause “Brown Out” issues when combined with Savox servos. An external BEC, or BEC stabilizing receiver capacitormay be needed for efficient, glitch free operation in low voltage electric applications.
Specifications:
- Torque:
- @6.0V:138.9 oz-in.
- Speed:
- @6.0V:0.07sec/60°
- Voltage Range:6.0v
- Weight: 62g
- Motor:Brushless
- Gear:Metal
- Case:Aluminum Heatsink
- Output Shaft:25T Spline (Futaba)
- Dimensions (LxWxH): 40.8×20.2×25.4mm
- Frequency:250-333hz
- Pulse Width Frequency: 1520
- Wire Length: 55mm
This product was added to our catalog on November 23, 2015
Darren Eisenhardt Verified Owner Saturday, Apr 28 2018 (about 7 years ago) Savox SB-2263MG Black Edition High Speed Low Profile Brushless Metal Gear Servo Needed to replace my servo in my Serpent SDX4 so I like Savox servo’s and thought that I’d give the SB-2263-BE a shot, and all I can say is i’m glad I did. Super smooth and fast with plenty of torque, plus all metal gears. Awesome servo Savox 3 customers found this review helpful. TirthankarRon Chatterjee Verified Owner Monday, Apr 22 2024 (about a year ago) Savox SB-2263MG Black Edition High Speed Low Profile Brushless Metal Gear Servo Great Servo I installed at my friend on road car. So far no complained . Carlos Pagan Verified Owner Friday, Nov 29 2019 (about 5 years ago) Savox SB-2263MG Black Edition High Speed Low Profile Brushless Metal Gear Servo i think these are the best bang for your buck servo. good speed great torque . 1 of 2 customers found this review helpful. View all reviews
